Chevrolet Silverado - Crew Cab Dimensions (2015-2019)

Rjluna2, CC BY-SA 4.0, via Wikimedia Commons

On this page you'll find the exact dimensions for the Chevrolet Silverado Crew Cab 3500HD generation 3, made from 2015 to . Below we'll list the dimensions for this pickup from verified sources. First, let's make sure you have the right dimensions in front of you:

Are these dimensions right for you?

Production years: 2015 - present Generation: 3 Type of van: pickup Model variant: 3500HD Body style: Crew Cab Also known as: GMC Sierra Chevrolet Cheyenne VIA Vtrux Truck Chevrolet Silverado LD

Dimensions in tables

Silverado truck bed dimensions (Crew Cab)

Truck bed dimensions Standard Box (6'6") Long Box (8')
Volume (cu. ft.) 60.7 75.5
Length at floor 78.8 97.8
Inside height 21 21
Width at wheelhouse 50.6 50.6
Maximum width at floor 62.4 62.4

Wheelbase of the Silverado:

Wheelbase Length (inch)
Standard Box (6'6") 153.7
Long Box (8') 167.7

Exterior dimensions of the Silverado Crew Cab:

Dimension 4x2 4x4
Overall length - Standard Box (6'6") 240.2 240.2
Overall length - Long Box (8') 259.1 259.1
Cab length 150.9 150.9
Height - Standard Box (6'6") 77.4 77.4
Height - Long Box (8') 77.9 77.9

Exterior width of the Crew Cab:

Exterior width 4x2 4x4
Overall width SRW - Standard Box (6'6") 80 80
Overall width SRW - Long Box (8') 80 80
Overall width DRW - Long Box (8') 95.9 95.9

Crew Cab miscellaneous dimensions

Miscellaneous dimensions 4x2 4x4
Min. ground clearance - Standard Box (6'6") 10.1 10
Min. ground clearance - Long Box (8') 9.7 9.6
Cab length 150.9 150.9

Interior dimensions

1st row dimensions Crew Cab
Head room 41.3
Shoulder room 65.2
Hip room 60.3
Leg room 41.3
2nd row dimensions Crew Cab
Head room 40.6
Shoulder room 65.2
Hip room 65.5
Leg room 39

Turning circle of the Silverado:

Turning circle: Kerb-to-kerb Wall-to-wall
SRW - Standard Box (6'6") 50.5
SRW - Long Box (8') 54.8
DRW - Long Box (8') 55.4
