On this page you'll find the exact dimensions for the Dodge Dakota Extended Cab Base generation 3, made from 2005 to . Below we'll list the dimensions for this pickup from verified sources. First, let's make sure you have the right dimensions in front of you:

---

Dimensions in tables

Dakota truck bed dimensions (Extended Cab)

Truck bed dimensions	Long Box
Volume (cu. ft.)	46.6
Length at floor	78.8
Inside height	17.6
Width at wheelhouse	45.2
Maximum width at floor	59.6

Wheelbase of the Dakota:

Wheelbase	Length (inch)
Long box	131.3

Exterior dimensions of the Dakota Extended Cab:

Dimension	4x2	4x4
Total length - Long Box	218.5	218.5
Total height - Long Box	68	68

Exterior width of the Extended Cab:

Exterior width	4x2	4x4
Total width - Long Box	71.7	71.7

Extended Cab miscellaneous dimensions

Miscellaneous dimensions	4x2	4x4
Overhang - Front	38.4	38.4
Overhang - Rear	48.8	48.8
Ground clearance, front - Long Box	7.9	7.9
Ground clearance, rear - Long Box	8	8
Ground to top of load floor - Long Box	31.2	31.2

Interior dimensions

1st row dimensions	Extended Cab
Head room	39.7
Shoulder room	57.7
Hip room	54.9
Leg room	41.9
2nd row dimensions	Extended Cab
Head room	36.6
Shoulder room	57.4
Hip room	52.5
Leg room	32.1

Turning circle of the Dakota:

Turning circle:	Kerb-to-kerb	Wall-to-wall
Long box	44
