Truck bed dimensions for short wheelbase models

The Ford Super Duty 2nd Generation Regular Cab LWB truck bed is 98" long at floor and 69.3" wide. The width between the wheelhouse is 50.9" and the cargo box height is 20.1". This results in a volume of 77.4 cu. ft.

---

Dimensions in tables

Jump to dimension: truck bed outside inside wheelbase clearance load height

Truck bed dimensions

Truck bed dimensions	4x2 SWB	4x4 SWB	4x2 LWB	4x4 LWB
Volume (cu. ft.)	77.4	77.4
Length at floor	98	98
Cargo box height	20.1	20.1
Width at wheelhouse	50.9	50.9
Maximum width at floor	69.3	69.3

Wheelbase of the Super Duty:

Wheelbase length:	4x2	4x4
Short (5.5')	137	137

Exterior dimensions of the Super Duty:

	4x2 SWB	4x4 SWB	4x2 LWB	4x4 LWB
Overall length	227	227
Height F250 SRW	75.9	79.2
Height F350 SRW	76	80.2
Height F350 DRW	76.1	79.4

Exterior width of the Super Duty:

Exterior width	4x2	4x4
Width (excluding mirrors)	79.9	79.9
Width (including standard mirrors)	99.6	99.6

Interior dimensions

1st row	4x2 SWB	4x4 SWB	4x2 LWB	4x4 LWB
Head room	41.4	41.4
Shoulder room	68	68
Hip room	67.6	67.6
Leg room	41	41
