RAM 1500 - Crew Cab Dimensions (2009-2019)

By Ruben de Rijcke - Own work, CC BY-SA 4.0

On this page you'll find the exact dimensions for the RAM 1500 Crew Cab 1500 generation 4, made from 2009 to . Below we'll list the dimensions for this pickup from verified sources. First, let's make sure you have the right dimensions in front of you:

Are these dimensions right for you?

Production years: 2009 - present Generation: 4 Type of van: pickup Model variant: 1500 Body style: Crew Cab Also known as: Ram 1500 Ram 1500 Classic Ram 2500/3500 Ram 4000 Dodge Ram ASV Ram

Dimensions in tables

1500 truck bed dimensions (Crew Cab)

Truck bed dimensions Short Box (5'7") Standard Box (6'4")
Volume (cu. ft.) 53.9 61.5
Length at floor 67.4 76.3
Inside height
Width at wheelhouse 51 51
Maximum width at floor

Wheelbase of the 1500:

Wheelbase Length (inch)
Short Box (5'7") 144.6
Standard Box (6'4") 153.5

Exterior dimensions of the 1500 Crew Cab:

Dimension 4x2 4x4
Overall length - Short Box (5'7") 232.9 232.9
Overall length - Standard Box (6'4") 241.8 241.8
Height - Short Box (5'7") 77.5 77.6
Height - Standard Box (6'4") 77.4 77.5

Exterior width of the Crew Cab:

Exterior width 4x2 4x4
Overall width - Short Box (5'7") 82.1 82.1
Overall width - Standard Box (6'4") 82.1 82.1

Crew Cab miscellaneous dimensions

Miscellaneous dimensions 4x2 4x4
Min. ground clearance - Short Box (5'7") 8.3 8.7
Min. ground clearance - Standard Box (6'4") 8.3 8.6

Interior dimensions

1st row dimensions Crew Cab
Head room 40.9
Shoulder room 66
Hip room 63.4
Leg room 40.9
2nd row dimensions Crew Cab
Head room 39.8
Shoulder room 65.7
Hip room 63.4
Leg room 45.2
