Toyota Tacoma - Double Cab Dimensions (2007-2021)

U.S. National Highway Traffic Safety Administration, Public domain, via Wikimedia Commons

On this page you'll find the exact dimensions for the Toyota Tacoma Double Cab Base generation 2, made from 2007 to . Below we'll list the dimensions for this pickup from verified sources. First, let's make sure you have the right dimensions in front of you:

Are these dimensions right for you?

Production years: 2007 - present Generation: 2 Type of van: pickup Model variant: Base Body style: Double Cab

Dimensions in tables

Tacoma truck bed dimensions (Double Cab)

Truck bed dimensions Standard Box (6.5') Long Box (8')
Volume (cu. ft.)
Length at floor 78.7 97.6
Inside height
Width at wheelhouse 50 50
Maximum width at floor

Wheelbase of the Tacoma:

Wheelbase Length (inch)
Standard Box (6.5') 145.7
Long Box (8') 164.6

Exterior dimensions of the Tacoma Double Cab:

Dimension 4x2 4x4
Overall length - Standard Box (6.5') 228.9 228.9
Overall length - Long Box (8') 247.8 247.8
Height - Standard Box (6.5') 76 76.4
Height - Standard Box (6.5') 76 76.2
Height - Standard Box (6.5') 77.2
Height - Long Box (8') 76 76.4

Exterior width of the Double Cab:

Exterior width 4x2 4x4
Overall width - Standard Box (6.5') 79.9 79.9
Overall width - Long Box (8') 79.9 79.9

Double Cab miscellaneous dimensions

Miscellaneous dimensions 4x2 4x4
Min. ground clearance - Standard Box (6.5') 10.2 10.6
Min. ground clearance - Standard Box (6.5') 10.2 10.4
Min. ground clearance - Standard Box (6.5') 10.6
Min. ground clearance - Long Box (8') 79.9 79.9

Interior dimensions

1st row dimensions Double Cab
Head room 39.7
Shoulder room 62.6
Hip room 42.5
Leg room 65.7
2nd row dimensions Double Cab
Head room 38.7
Shoulder room 62.6
Hip room 34.7
Leg room 65.6
