Dodge RAM - Regular Cab Dimensions (2002-2009)
On this page you'll find the exact dimensions for the Dodge RAM Regular Cab 2500 generation 3, made from 2002 to . Below we'll list the dimensions for this pickup from verified sources. First, let's make sure you have the right dimensions in front of you:
Are these dimensions right for you?
Production years: 2002 - present Generation: 3 Type of van: pickup Model variant: 2500 Body style: Regular Cab Also known as: Sterling BulletDimensions in tables
RAM truck bed dimensions (Regular Cab)
Truck bed dimensions | Long Box (8') |
---|---|
Volume (cu. ft.) | 74.9 |
Length at floor | 98.3 |
Inside height | 20.2 |
Width at wheelhouse | 51 |
Maximum width at floor | 65.1 |
Wheelbase of the RAM:
Wheelbase | Length (inch) |
---|---|
Long Box (8') | 140.5 |
Exterior dimensions of the RAM Regular Cab:
Dimension | 4x2 | 4x4 |
---|---|---|
Overall length - Long Box (8') | 229.7 | 229.7 |
Height - Long Box (8') | 74.3 | 78.4 |
Exterior width of the Regular Cab:
Exterior width | 4x2 | 4x4 |
---|---|---|
Width (mirrors folded) | 79.6 | 79.6 |
Regular Cab miscellaneous dimensions
Miscellaneous dimensions | 4x2 | 4x4 |
---|---|---|
Overhang - Front | 39.3 | 39.4 |
Overhang - Rear | 49.9 | 49.9 |
Ground to top of load floor - Long Box (8') | 33 | 36.6 |
Ground Clearance, Rear - Long Box (8') | 7.4 | 7.4 |
Interior dimensions
1st row dimensions | Regular Cab |
---|---|
Head room | 40.8 |
Shoulder room | 67 |
Hip room | 65 |
Leg room | 41 |
Turning circle of the RAM:
Turning circle: | Kerb-to-kerb | Wall-to-wall |
---|---|---|
Long Box (8') | 48.9 |
