On this page you'll find the exact dimensions for the Ford Ranger USA 3 Regular Cab Base generation 3, made from 1998 to . Below we'll list the dimensions for this pickup from verified sources. First, let's make sure you have the right dimensions in front of you:

---

Dimensions in tables

Ranger USA 3 truck bed dimensions (Regular Cab)

Truck bed dimensions
Volume (cu. ft.)	37.4
Length at floor	72.7
Inside height	16.5
Width at wheelhouse	40.5
Maximum width at floor	54.4

Wheelbase of the Ranger USA 3:

Wheelbase	Length (inch)
Standard box	111.5

Exterior dimensions of the Ranger USA 3 Regular Cab:

Dimension	4x2	4x4
Overall length - Standard Box	189.4
Height - Standard Box	66.2

Exterior width of the Regular Cab:

Exterior width	4x2	4x4
Width (excluding mirrors)	69.3
Width (including mirrors)	81.3

Regular Cab miscellaneous dimensions

Miscellaneous dimensions	4x2	4x4
Overhang - Front	34
Overhang - Rear	44
Ground clearance	8.9
Load floor height	29.7

Interior dimensions

1st row dimensions	Standard Box
Head room	39.2
Shoulder room	54.5
Hip room	52.7
Leg room	42.4
