On this page you'll find the exact dimensions for the Ford Ranger USA 3 Super Cab Base generation 3, made from 1998 to . Below we'll list the dimensions for this pickup from verified sources. First, let's make sure you have the right dimensions in front of you:

---

Dimensions in tables

Ranger USA 3 truck bed dimensions (Super Cab)

Truck bed dimensions	Standard Box
Volume (cu. ft.)	37.4
Length at floor	72.7
Inside height	16.5
Width at wheelhouse	40.5
Maximum width at floor	54.4

Wheelbase of the Ranger USA 3:

Wheelbase	Length (inch)
Standard box 4X2	125.7
Standard box 4X4	125.9

Exterior dimensions of the Ranger USA 3 Super Cab:

Dimension	4x2	4x4
Overall length - Standard Box	203.6	203.6
Height - Standard Box	66.3	67.7

Exterior width of the Super Cab:

Exterior width	4x2	4x4
Width (excluding mirrors)	69.4	71.3
Width (including standard mirrors)	81.3	81.3

Super Cab miscellaneous dimensions

Miscellaneous dimensions	4x2	4x4
Overhang - Front	34	34
Overhang - Rear	44	43.8
Ground clearance	8.6	8.2
Load floor height	29.5	31.9

Interior dimensions

1st row dimensions	All models
Head room	39.2
Shoulder room	54.5
Hip room	52.7
Leg room	42.4
2nd row dimensions	All models
Head room	33.2
Shoulder room	14.1
Hip room	18.7
Leg room	39.1
