Are these dimensions right for you?
Production years:
1999 -
2007
Generation:
1
Type of van:
pickup
Body styles:
CrewCab
Also called:
F-250
F-350
F-450
F-550
F-4000
Dimensions in tables
Jump to dimension:
truck bed
outside
inside
wheelbase
clearance
load height
Truck bed dimensions
| Truck bed dimensions |
4x2 SWB |
4x4 SWB |
4x2 LWB |
4x4 LWB |
| Volume (cu. ft.) |
64.8 |
64.8 |
77.8 |
77.8 |
| Length at floor |
82.4 |
82.4 |
98.6 |
98.6 |
| Cargo box height |
20 |
20 |
20 |
20 |
| Width at wheelhouse |
50.9 |
50.9 |
50.9 |
50.9 |
| Maximum width at floor |
63.5 |
63.5 |
63.5 |
63.5 |
Wheelbase of the Super Duty:
| Wheelbase length: |
4x2 |
4x4 |
| Short wheelbase (6.75') |
156.2 |
156.2 |
| Long wheelbase (8') |
172.4 |
172.4 |
Exterior dimensions of the Super Duty:
|
4x2 SWB |
4x4 SWB |
4x2 LWB |
4x4 LWB |
| Overall length |
245.6 |
245.6 |
261.8 |
261.8 |
| Height F250 SRW |
77.5 |
80 |
77.3 |
79.9 |
| Height F350 SRW |
77.8 |
81.8 |
77.6 |
81.7 |
| Height F350 DRW |
77.6 |
80.1 |
77.4 |
80 |
Exterior width of the Super Duty:
| Exterior width |
4x2 |
4x4 |
| Width (excluding mirrors) |
79.9 |
79.9 |
| Width (including standard mirrors) |
99.3 |
99.3 |
Interior dimensions
| 1st row |
4x2 SWB |
4x4 SWB |
4x2 LWB |
4x4 LWB |
| Head room |
41.3 |
41.3 |
41.3 |
41.3 |
| Shoulder room |
68 |
68 |
68 |
68 |
| Hip room |
67.4 |
67.4 |
67.4 |
67.4 |
| Leg room |
41 |
41 |
41 |
41 |
| 2nd row |
4x2 SWB |
4x4 SWB |
4x2 LWB |
4x4 LWB |
| Head room |
40.8 |
40.8 |
40.8 |
40.8 |
| Shoulder room |
68 |
68 |
68 |
68 |
| Hip room |
67.3 |
67.3 |
67.3 |
67.3 |
| Leg room |
41.7 |
41.7 |
41.7 |
41.7 |
