Image from: Stellantis Media
RAM 3500 HD - Mega Cab Dimensions (2009-2019)
On this page you'll find the exact dimensions for the RAM 3500 HD Mega Cab 3500 HD generation 4, made from 2009 to . Below we'll list the dimensions for this pickup from verified sources. First, let's make sure you have the right dimensions in front of you:
Are these dimensions right for you?
Production years: 2009 - present Generation: 4 Type of van: pickup Model variant: 3500 HD Body style: Mega Cab Also known as: Ram 1500 Ram 1500 Classic Ram 2500/3500 Ram 4000 Dodge Ram ASV RamDimensions in tables
3500 HD truck bed dimensions (Mega Cab)
| Truck bed dimensions | Standard Box (6'4") |
|---|---|
| Volume (cu. ft.) | |
| Length at floor | |
| Inside height | |
| Width at wheelhouse | 51 |
| Maximum width at floor |
Wheelbase of the 3500 HD:
| Wheelbase | Length (inch) |
|---|---|
| Standard Box (6'4") | 160.2 |
Exterior dimensions of the 3500 HD Mega Cab:
| Dimension | 4x2 | 4x4 |
|---|---|---|
| Overall length - Standard Box (6'4") | 248.4 | 248.4 |
| Overall length - Standard Box (6'4") DRW | 248.4 | 248.4 |
| Height - Standard Box (6'4") | 78.3 | 79.7 |
| Height - Standard Box (6'4") DRW | 77.5 | 79 |
Exterior width of the Mega Cab:
| Exterior width | 4x2 | 4x4 |
|---|---|---|
| Overall width - Standard Box (6'4") | 79.4 | 79.4 |
| Overall width - Standard Box (6'4") DRW | 96.4 | 96.4 |
Interior dimensions
| 1st row dimensions | Mega Cab |
|---|---|
| Head room | 41 |
| Shoulder room | 66 |
| Hip room | 63.2 |
| Leg room | 41 |
| 2nd row dimensions | Mega Cab |
| Head room | 40.3 |
| Shoulder room | 65.7 |
| Hip room | 63.2 |
| Leg room | 43.3 |
