Are these dimensions right for you?
Production years:
2011 -
2016
Generation:
3
Type of van:
pickup
Body styles:
Crew Cab
Also called:
F-250
F-350
F-450
F-550
Dimensions in tables
Jump to dimension:
truck bed
outside
inside
wheelbase
clearance
load height
Truck bed dimensions
| Truck bed dimensions |
4x2 SWB |
4x4 SWB |
4x2 LWB |
4x4 LWB |
| Volume (cu. ft.) |
64.1 |
64.1 |
77.3 |
77.3 |
| Length at floor |
81.8 |
81.8 |
98 |
98 |
| Cargo box height |
20 |
20 |
20 |
20 |
| Width at wheelhouse |
50.9 |
50.9 |
50.9 |
50.9 |
| Maximum width at floor |
69.3 |
69.3 |
69.3 |
69.3 |
Wheelbase of the Super Duty:
| Wheelbase length: |
4x2 |
4x4 |
| Short wheelbase (6.75') |
156.2 |
156.2 |
| Long wheelbase (8') |
172.4 |
172.4 |
Exterior dimensions of the Super Duty:
|
4x2 SWB |
4x4 SWB |
4x2 LWB |
4x4 LWB |
| Overall length |
246.8 |
246.8 |
263 |
263 |
| Height F250 SRW |
77.4 |
79.7 |
77.3 |
79.8 |
| Height F350 SRW |
77.2 |
80.8 |
77.2 |
80.8 |
| Height F350 DRW |
|
|
77.3 |
79.9 |
| Height F450 DRW |
|
|
79.7 |
79.7 |
Exterior width of the Super Duty:
| Exterior width |
4x2 |
4x4 |
| Width (excluding mirrors) |
79.9 |
79.9 |
| Width (excluding mirrors) |
96 |
96 |
| Width (including standard mirrors) |
104.9 |
104.9 |
| Width (including trailer tow mirrors) |
110 |
110 |
Interior dimensions
| 1st row |
4x2 SWB |
4x4 SWB |
4x2 LWB |
4x4 LWB |
| Head room |
40.7 |
40.7 |
40.7 |
40.7 |
| Shoulder room |
68 |
68 |
68 |
68 |
| Hip room |
67.6 |
67.6 |
67.6 |
67.6 |
| Leg room |
41.1 |
41.1 |
41.1 |
41.1 |
| 2nd row |
4x2 SWB |
4x4 SWB |
4x2 LWB |
4x4 LWB |
| Head room |
40.8 |
40.8 |
40.8 |
40.8 |
| Shoulder room |
68 |
68 |
68 |
68 |
| Hip room |
67.6 |
67.6 |
67.6 |
67.6 |
| Leg room |
42.1 |
42.1 |
42.1 |
42.1 |
