Dimensions of the Ford Super Duty - (2011-2016) - SuperCab

Are these dimensions right for you?

Production years: 2011 - 2016 Generation: 3 Type of van: pickup Body styles: SuperCab Also called: F-250 F-350 F-450 F-550

Dimensions in tables

Truck bed dimensions

Truck bed dimensions 4x2 SWB 4x4 SWB 4x2 LWB 4x4 LWB
Volume (cu. ft.) 64.1 64.1 77.3 77.3
Length at floor 81.8 81.8 98 98
Cargo box height 20 20 20 20
Width at wheelhouse 50.9 50.9 50.9 50.9
Maximum width at floor 69.3 69.3 69.3 69.3

Wheelbase of the Super Duty:

Wheelbase length: 4x2 4x4
Short wheelbase (6.75') 141.8 141.8
Long wheelbase (8') 158 158

Exterior dimensions of the Super Duty:

4x2 SWB 4x4 SWB 4x2 LWB 4x4 LWB
Overall length 232.4 232.4 248.6 248.6
Height F250 SRW 77 79.5 76.9 79.3
Height F350 SRW 76.9 80.4 76.7 80.2
Height F350 DRW 76.9 79.7

Exterior width of the Super Duty:

Exterior width 4x2 4x4
Width (excluding mirrors) 79.9 79.9
Width (excluding mirrors) 96 96
Width (including standard mirrors) 104.9 104.9
Width (including trailer tow mirrors) 110 110

Interior dimensions

1st row 4x2 SWB 4x4 SWB 4x2 LWB 4x4 LWB
Head room 40.7 40.7 40.7 40.7
Shoulder room 68 68 68 68
Hip room 67.6 67.6 67.6 67.6
Leg room 41.1 41.1 41.1 41.1
2nd row 4x2 SWB 4x4 SWB 4x2 LWB 4x4 LWB
Head room 38.1 38.1 38.1 38.1
Shoulder room 68.1 68.1 68.1 68.1
Hip room 67.3 67.3 67.3 67.3
Leg room 31.6 31.6 31.6 31.6
