Dimensions for the Ford Super Duty (2011-2016) - Regular Cab
Are these dimensions right for you?
Production years: 2011 - 2016 Generation: 3 Type of van: pickup Body styles: Regular Also called: F-250 F-350 F-450 F-550Dimensions in tables
Truck bed dimensions
| Truck bed dimensions | 4x2 SWB | 4x4 SWB | 4x2 LWB | 4x4 LWB |
|---|---|---|---|---|
| Volume (cu. ft.) | 77.3 | 77.3 | ||
| Length at floor | 98 | 98 | ||
| Cargo box height | 20 | 20 | ||
| Width at wheelhouse | 50.9 | 50.9 | ||
| Maximum width at floor | 69.3 | 69.3 |
Wheelbase of the Super Duty:
| Wheelbase length: | 4x2 | 4x4 |
|---|---|---|
| Long wheelbase (8') | 137 | 137 |
Exterior dimensions of the Super Duty:
| 4x2 SWB | 4x4 SWB | 4x2 LWB | 4x4 LWB | |
|---|---|---|---|---|
| Overall length | 227.6 | 227.6 | ||
| Height F250 SRW | 76.6 | 79.2 | ||
| Height F350 SRW | 76.5 | 80 | ||
| Height F350 DRW | 76.7 | 79.5 |
Exterior width of the Super Duty:
| Exterior width | 4x2 | 4x4 |
|---|---|---|
| Width (excluding mirrors) | 79.9 | 79.9 |
| Width (excluding mirrors) | 96 | 96 |
| Width (including standard mirrors) | 104.9 | 104.9 |
| Width (including trailer tow mirrors) | 110 | 110 |
Interior dimensions
| 1st row | 4x2 SWB | 4x4 SWB | 4x2 LWB | 4x4 LWB |
|---|---|---|---|---|
| Head room | 40.7 | 40.7 | ||
| Shoulder room | 68 | 68 | ||
| Hip room | 67.6 | 67.6 | ||
| Leg room | 41.1 | 41.1 |
