Isuzu D-Max - Crew Cab Dimensions (2019-)
On this page you'll find the exact dimensions for the Isuzu D-Max Crew Cab SX, LS-M, LS-U, LS-T generation 3, made from 2019 and currently still being produced. Below we'll list the dimensions for this pickup from verified sources. First, let's make sure you have the right dimensions in front of you:
Are these dimensions right for you?
Production years: 2019 - present Generation: 3 Type of van: pickup Model variant: SX LS-M LS-U LS-T Body style: Crew Cab Also known as: RG01Dimensions in tables
D-Max truck bed dimensions (Crew Cab)
| Truck bed dimensions | Crew Cab |
|---|---|
| Volume (cu. ft.) | |
| Length at floor | 1552 |
| Inside height | 465 |
| Width at wheelhouse | 1105 |
| Maximum width at floor | 1530 |
Wheelbase of the D-Max:
| Wheelbase | Length (inch) |
|---|---|
| Wheelbase (mm) | 3095 |
Exterior dimensions of the D-Max Crew Cab:
| Dimension | 4x2 | 4x4 |
|---|---|---|
| Overall length (mm) | 5295 | 5295 |
| Overall height (mm) | 1855 | 1855 |
Exterior width of the Crew Cab:
| Exterior width | 4x2 | 4x4 |
|---|---|---|
| Overall width - excluding door mirrors (mm) | 1860 | 1860 |
Crew Cab miscellaneous dimensions
| Miscellaneous dimensions | 4x2 | 4x4 |
|---|---|---|
| Front overhang (mm) | 905 | 905 |
| Rear overhang (mm) | 1295 | 1295 |
| Ground clearance (mm) | 235 | 235 |
Interior dimensions
| 1st row dimensions | Crew Cab |
|---|---|
| Head room | 1005 |
| Shoulder room | 1460 |
| Hip room | |
| Leg room | 1070 |
| 2nd row dimensions | Crew Cab |
| Head room | |
| Shoulder room | |
| Hip room | |
| Leg room | 915 |
Turning circle of the D-Max:
| Turning circle: | Kerb-to-kerb | Wall-to-wall |
|---|---|---|
| Turning circle diameter between kerbs (m) | 12.6 |
